| Item | Range | Thread Length | Thread O.D. | Joint Length | Spanner size | Code |
| M64×2 | 37-44 | 14 | 64 | 38 | 64/68 | HX-NPM64 |
| M70×2 | 42-52 | 16 | 70 | 44 | 78 | HX-NPM70 |
| M72×2 | 42-52 | 16 | 72 | 44 | 78 | HX-NPM72 |
| M72×2 | 48-58 | 16 | 72 | 44 | 78 | HX-NPM72-58 |
| M75×2 | 42-52 | 16 | 75 | 44 | 78/80 | HX-NPM75 |
| M75×2 | 48-58 | 16 | 75 | 44 | 78/80 | HX-NPM75-58 |
| M80×2 | 55-62 | 18 | 80 | 45 | 88 | HX-NPM80 |
| M88×2 | 65-70 | 18 | 88 | 45 | 94 | HX-NPM88 |
| M100×2 | 78-84 | 20 | 100 | 53 | 110 | HX-NPM100 |
| M120×2 | 78-84 | 20 | 120 | 53 | 110/130 | HX-NPM120 |
Here are some details:
1.This type of cable gland is typically made of nickel-plated brass.
2.It provides a hermetic seal that completely blocks out external water, oil, and dust, protecting internal precision parts.
3.The super large type is available in different configurations, including M64×2 with a range of 37-44, and M70×2 with a range of 42-52.
4.The protection degree is IP68-10 bar.
