| Modle | Conductor Range(mm2） | |
| Main | Tap | |
| ABS | (25-70) | (6-35) |
| SMMA-1 | (16-95) | (16-25) |
| SMMA-2 | (70-95) | (70-95) |
| SMHA | (70-185) | (70-120) |
| CPA | (16-70) | (16-70) |
| DP10 | (50-70) | (50-70) |
Here are the key details:
1.Composition:
1)The blades of the connector are made of tin-plated copper or aluminum alloy.
2)Suitable for connecting aluminum and/or copper stranded conductors.
2.Installation Process:
1)Insert the cable branch line terminal into the waterproof terminal.
2)Determine the location for the main line branch.
3)Tighten the torque nut on the clamp using a socket wrench.
4)The piercing blade penetrates the cable insulation layer, making contact with the conductor.
5)Sealing gaskets ensure weatherproofing.
6)Silicone grease provides additional protection.
3.Advantages:
1)No need to strip insulation.
2)Efficient installation.
3)Reliable performance in low voltage overhead distribution networks.
