| Modle | Conductor Range(mm2) | |
| Main (AICu)(mm2) | Tap (AICu)(mm 2) | |
| DCNL-1 | (10-95) | （1.5-10） |
| DCNL-2 | (16-95) | （4-35） |
| DCNL-3 | (25-120) | （25-95） |
| DCNL-4 | (50-150） | （4-35） |
| DCNL-5 | （35-150） | （35-150） |
| DCNL-1D | （10-95） | （1.5-10） |
| DCNL-4D | （50-150） | （4-35） |
Here are the key points:
1.Functionality:
1)The DCNL allows for quick and reliable connections between insulated conductors.
2)It pierces the insulation of the cable to establish electrical contact.
3)Suitable for low voltage overhead distribution networks.
2.Design Features:
1)The connector body is made of insulating material.
2)Tin-plated copper blades are embedded in the body.
3)Torque control nut ensures proper connection.
4)Waterproof end caps for outdoor use.
3.Advantages:
1)No need for stripping insulation.
2)Efficient installation.
3)Reliable performance in various environments.
