| Catalog No. | Hole1 mm2 | Hole2 mm2 | Dimensions(mm) | ||
| A | B | L | |||
| CPTG10-16/10-16 | 16-35 | 16-35 | 17.5 | 23.8 | 38 |
| CPTG16-35/10-16 | 16-35 | 35-70 | 17.8 | 26 | 46 |
| CPTG16-35/16-35 | 35-70 | 35-70 | 20.6 | 30.5 | 47 |
| CPTG50-70/10-16 | 70-120 | 70-120 | 22.7 | 36.5 | 52 |
| CPTG50-70/16-35 | 35-150 | 70-150 | 23 | 34.5 | 70 |
| CPTG50-70/50-70 | 70-150 | 70-150 | 25.4 | 39.5 | 70 |
| CPTG70-150/50-70 | 35-70 | 120-240 | 28 | 42 | 90 |
| CPTG70-150/70-150 | 70-150 | 120-240 | 32 | 46 | 90 |
| CPTG150-240/70-150 | 120-240 | 120-240 | 32 | 52 | 90 |
| CPTG150-240/150-240 | 150-300 | 150-300 | 32 | 52 | 100 |
