| Modle | Conductor Cross-section(mm2) | Bolts |
| APG-A1 | Al 16-70 | 1×M8×40 |
| APG-A2 | Al 16-150 | 1×M8×45 |
| APG-B1 | Al 16-35 | 2×M6×35 |
| APG-B2 | Al 16-70 | 2×M8×45 |
| APG-B3 | Al 16-150 | 2×M8×50 |
| APG-B4 | Al 25-185 | 2×M10×60 |
| APG-C1 | Al 16-70 | 3×M8×45 |
| APG-C2 | Al 16-150 | 3×M8×50 |
| APG-C3 | Al 25-240 | 3×M10×60 |
| APG-C4 | Al 35-300 | 3×M10×70 |
Here are its key features:
1.Advanced Forging Technology: Enhances the mechanical strength of the clamp.
2.Slotted Holes: Allow adjustment for varying conductors on each side.
3.Bi-Metal Connection: Facilitates secure connections between aluminum and copper conductors.
