| Type | Rated voltage (kV) | Rated current (A) | Breaking current (kA) | Impulse voltage (kV) | Power frequency withstand voltage (kV) | Creepage distance (mm) | Weight (kg) | Dimension (cm) |
| THC2-33/100 | 33-36 | 100 | 8000 | 170 | 70 | 720 | 12 | 65×35×13.5 |
| THC2-33/200 | 33-36 | 200 | 10000 | 170 | 70 | 720 | 12.5 |
1.Features:
1)Rated Voltage:The voltage level at which the device can operate safely.
2)Rated Current:The maximum current the device can carry without tripping.
3)Breaking Current:The maximum fault current the device can interrupt.
4)Impulse Voltage:The withstand level for transient overvoltages, like lightning strikes.
5)Power-Frequency Withstand Voltage:The ability to withstand continuous operational voltage.
6)Creepage Distance:The distance along the insulating surface between conductive parts.
