| Type | Rated voltage (kV) | Rated current (A) | Breaking current (kA) | Impulse voltage (kV) | Power frequency withstand voltage (kV) | Creepage distance (mm) | Weight (kg) | Dimension (cm) |
| RW12-24/100A | 24-27 | 100 | 8000 | 150 | 65 | 540 | 9 | 50×38.5×14 |
| RW12-24/200A | 24-27 | 200 | 10000 | 150 | 65 | 540 | 9.4 |
1.Specifications:
1)Rated voltage: 24-27kV
2)Rated current:100A/200A
3)Breaking current:8000A/10000A
4)Impulse voltage (BIL):150kV
5)Power frequency withstand voltage:65kV
6)Creepage Distance:540mm
